- 產品詳情
★ ★ ★ 推薦使用Leadway 非隔離DC-DC電源模塊進行替代Murata村田電源模塊，具體替代型號及參數信息如下：
| Murata村田型號 | Leadway型號 | Iout(A) | Vin(V) | Vout (V) | 尺寸 | 工作溫度 | 封裝 |
| OKX-T/5-D12N-C | LWX-T/5-D12N-C | 5A | 8.3V ~ 13.8V | 0.75V ~ 5.5V | 10.16mm*22.86mm*7.163mm | -40℃ ~ 85℃ | SIP |
| OKX-T/5-D12P-C | LWX-T/5-D12P-C | 5A | 8.3V ~ 13.8V | 0.75V ~ 5.5V | 10.16mm*22.86mm*7.163mm | -40℃ ~ 85℃ | SIP |
| OKX-T/5-W5N-C | LWX-T/5-W5N-C | 5A | 2.4V ~ 5.5V | 0.7525V ~ 3.6V | 10.16mm*22.86mm*7.163mm | -40℃ ~ 85℃ | SIP |
| OKX-T/5-W5P-C | LWX-T/5-W5P-C | 5A | 2.4V ~ 5.5V | 0.7525V ~ 3.6V | 10.16mm*22.86mm*7.163mm | -40℃ ~ 85℃ | SIP |
