Vishay電容器BFC280908003

發布時間：2024-04-25 09:59:39 瀏覽：1125

　　Vishay 的這款BFC280908003微調電容器是一款可變電容器，可用于校準設備。它可以承受 250 VDC 的電壓。該微調電容器的最高工作溫度為 125 °C。本產品長10.9(最大)mm，高11(最大)mm，深10.5(最大)mm。

vishay電容器BFC280908003

　　特征：

　　高溫型

　　外殼尺寸：10 mm x 11 mm x 11 mm

　　對于 2.54 mm 的基本網格

　　應用：

　　天線

　　阻抗匹配電路

　　醫療

參數：

Bated DC voltag	250 V
Test DC voltage for 1 min	500 V
Maximum contact resistance	5 mg
Minimum insulation resistance	10000 MQ
Category temperature range	-40C to+125 C
Climatic category (IEC:60068	40/125/21
Minimum storage temperature	-55 ℃
Related specification	EC 60418-1 and 4
Effective angle of rotation	180°(rotation in 180 only,see "Life of trimmer"
Operating torque	2 mNm to 25 mNm
Maximum axial thrust	2 N
Capacitance range (Cmin./Cmax)	4 pF/38 pF to 5 pF/57 pF
fe of trimmer	Maximum 10 cycles:rotation in 180°only (the electrical and mechanical performance is not guaranteed if rotated beyond 10 cycles
Quality leve	Sampling and data evaluation for quality level in accordance with "M/L-STD-105D"and "IEC 60410: <0.15 %major defects <0.65 %minor defects Each capacitor is tested for minimum Cmax and is also subjected to the full test voltage
